Vertical Lift Door Box Quenching Furnace For Small Batch Die Steel Cutting Tools

This mini vertical lift door quenching furnace is developed for small-batch production, mold trial making and laboratory testing scenarios. The overall furnace volume is compact with small internal loading cavity, matching small-size cutting tools, tiny mold inserts and sample workpiece heat treatment.

It retains the automatic vertical lift door sealing structure of large models, with smaller power occupation and lower floor space demand. It is the best choice for small mold workshops, tool processing factories and R&D laboratories that only need small batch quenching every day.

Compact small furnace cavity quickly reaches target quenching temperature with low power consumption. Mini vertical lift door realizes fast automatic opening and closing for frequent sampling of small workpieces. The small internal space shortens heating and holding time, improving efficiency for trial production and small batch processing, without energy waste of large empty furnace cavity.

1. Side-Open Box Quenching Furnace Front door loading & unloading, external quenching tank. Suitable for small-batch molds and single parts with low cost.

2. Bottom Drop Rapid Box Quenching Furnace The furnace bottom automatically descends and submerges into the quenching tank. Transfer time ≤30 seconds to avoid workpiece temperature drop and decarburization. Designed for precision alloy steel and aerospace components.

3. Trolley-Type Box Quenching Furnace Equipped with automatic loading/unloading trolley, specially for heavy-tonnage forgings, flanges and shaft parts.

4. Controlled Atmosphere Box Quenching Furnace Filled with nitrogen or methanol cracking gas for oxidation-free bright quenching. Ideal for automotive fasteners and gears.

5. Vacuum Box Quenching Furnace Sealed vacuum environment realizes zero oxidation and ultra-smooth surface finish. Applied to high-end molds and aerospace precision components.

• Compact Mini Cavity Design For Small Parts Small-size furnace chamber, specially for drills, milling cutters, tiny mold inserts and lab test samples, no waste of heating energy for small batch.

• Small Floor Space & Low Power Consumption Small overall size, easy to place in small workshop or laboratory; low rated power, save electricity for intermittent small-batch production.

• Mini Automatic Vertical Lift Door Miniature lifting drive motor, one-button automatic door opening/closing, convenient for frequent small-batch feeding and sampling.

• Simple Operation For Trial Production Simplified PLC control panel with basic temperature curve programming function, easy for laboratory technicians to test different quenching processes.

1. Furnace Body: Thick steel plate & section steel welded shell, anti-rust coating

2. Insulation Lining: High-temperature resistant ceramic fiber module, light weight & shock resistance

3. Heating Element: OCr27Al7Mo2 high-resistance alloy strip, long service life

4. Furnace Door: Electric lifting / swing door with double-layer sealing to avoid heat leakage

5. Control Cabinet: PLC + PID intelligent temperature controller, S-type thermocouple

6. Quenching System: Separate oil/water quenching tank with circulation cooling device

7. Atmosphere System (Optional): Methanol cracking, nitrogen input, carbon potential precise control

8. Vacuum System (Optional): Vacuum pump unit for bright vacuum quenching

• Furnace Cavity: Compact mini size customized for small parts

• Lifting System: Mini electric vertical lift door

• Rated Power: Low power configuration for intermittent use

• Control: Simplified PLC temperature curve programming panel

• Applicable Workpieces: Cutting tools, small mold inserts, test samples

• Small cutting tool factory batch quenching (drill, end mill, tap)

• Small mold workshop trial production of tiny mold inserts

• Material laboratory heat treatment performance test

• Small hardware processing plant intermittent small-batch hardening

Q1: What’s the difference between this small lift door furnace and large automatic lift door model?

A: This mini version has smaller cavity, lower power and smaller footprint, only for small batch cutting tools and trial samples; large models are for mass auto/mold production.

Q2: Can I use this furnace for mass production?

A: Not recommended. It is designed for small batch trial production; choose large uniform temperature furnace if you need daily mass quenching processing.
